MTC-502XL Heavy Duty Cantilever Wall Mount

The NEW Heavy Duty MTC-502XL cantilever TV mount is a new heavy-duty model with a 620mm wide mounting wall plate holes, which is designed for Australian consumers wishing to easily install their larger TVs on timber stud walls at home by themselves. The dual arm design adds strength and stability to the unit. With a sleek, high-quality powder coated finish, this unit allows for quick installation of an LCD/LED display onto the wall plate. The wall plate cover and cable integration system ensure a neat look. With this full-motion TV mount, you can easily tilt, extend, and rotate your screen to achieve an optimal viewing angle for any situation.

This versatile design can hold a flat panel TV close to the wall, only protruding by 108mm, yet still allowing level and tilt adjustment as well as swivel of the screen.

This advanced design makes achieving the proper viewing angle easy and convenient. The cable management system makes your cable connections straightforward and neat. The standard accessories enable you to extend the VESA TV mount holes from 200 x 200, 800 x 400mm. The arm can extend to a maximum of 785mm.

Specifications:

Fits screen sizes 40" - 90" (Guide)

VESA 200 x 200 to 800 x 400

Tilting range -5° to +15°, 180°Swivel

Level adjust +/- 6°

Concealed Cable Management

Load capacity: 90kg

660mm wall plate and 785mm extension
